Product Details
Place of Origin: China
Brand Name: LHTi
Model Number: Titanium sheet
Payment & Shipping Terms
Length: |
2000mm |
Advantage: |
Chinese Titanium Valley |
Tensile Strength: |
240 MPa |
Package: |
Wooden Case |
Grade: |
GR5, Gr7, Gr9 |
Unit Price: |
$15.5-$36.9/kg |
Electrical Conductivity: |
Low |
Surface: |
Rolling Surface |
Use: |
Chemical |
Yield Strength: |
P.S.I. = 25000 |
Thicknes: |
15mm 20mm 25mm |
Finishing: |
Pickling, Machining, Abrasive Blasting |
Regular Size: |
4*8ft/ 4*10ft/ 1500*3000mm |
Mtc: |
EN10204.3.1 Certificate |
Material Grade: |
Titanium Gr2 |
Length: |
2000mm |
Advantage: |
Chinese Titanium Valley |
Tensile Strength: |
240 MPa |
Package: |
Wooden Case |
Grade: |
GR5, Gr7, Gr9 |
Unit Price: |
$15.5-$36.9/kg |
Electrical Conductivity: |
Low |
Surface: |
Rolling Surface |
Use: |
Chemical |
Yield Strength: |
P.S.I. = 25000 |
Thicknes: |
15mm 20mm 25mm |
Finishing: |
Pickling, Machining, Abrasive Blasting |
Regular Size: |
4*8ft/ 4*10ft/ 1500*3000mm |
Mtc: |
EN10204.3.1 Certificate |
Material Grade: |
Titanium Gr2 |
In the ever-evolving landscape of medical technology, materials play a crucial role in the efficacy and safety of surgical procedures. Among these materials, ASTM F136 titanium plates and sheets have gained significant recognition in the medical industry, particularly in orthopedic and implant surgeries. ASTM F136 is a specification for titanium alloy used in the manufacturing of implants and devices, characterized by its biocompatibility, strength, and lightweight properties. These features make it an ideal choice for a range of medical applications, including fracture fixation, spinal surgeries, and craniofacial reconstruction.
ASTM F136 titanium is known for its unique properties that contribute to its widespread use in medical applications. One of the most significant attributes is its biocompatibility, which ensures that the material can coexist with human tissue without causing adverse reactions. This is essential for implants that remain in the body for extended periods, as it minimizes the risk of infection and rejection. Additionally, titanium exhibits excellent corrosion resistance, a critical factor considering the challenging biological environment of the human body. This resistance helps maintain the structural integrity of implants over time, reducing the likelihood of device failure.
The strength-to-weight ratio of ASTM F136 titanium is another vital aspect that makes it suitable for medical applications. Titanium is both strong and lightweight, providing the necessary support for fractures while minimizing additional load on the skeletal system. This feature not only enhances patient comfort during recovery but also allows for greater mobility, which is crucial in the rehabilitation process. The combination of these properties makes ASTM F136 titanium an ideal material for use in various surgical implants and fixation devices.
The versatility of ASTM F136 titanium plates and sheets has led to their widespread adoption across various medical specialties. In orthopedic surgery, these materials are commonly used for stabilizing fractures in long bones, such as the femur and tibia. The ability to customize titanium plates during surgery allows orthopedic surgeons to achieve precise fit and alignment, which is critical for effective healing. Moreover, the lightweight nature of titanium reduces the overall burden on the patient, facilitating quicker recovery times and improved outcomes.
In spinal surgery, titanium plates and rods are essential for stabilizing the vertebrae during procedures like spinal fusion. The mechanical strength of ASTM F136 titanium provides the necessary support to maintain spinal alignment while promoting bone healing. Its biocompatibility ensures that the material integrates well with the body, minimizing complications associated with implant placement. This has made titanium a preferred choice for surgeons dealing with complex spinal conditions, including degenerative diseases and trauma.
The use of ASTM F136 titanium also extends to maxillofacial surgery, where it plays a pivotal role in reconstructing facial bones following trauma or congenital defects. Titanium plates can be shaped and customized to fit the contours of the patient's facial structure, ensuring both functional restoration and aesthetic considerations. The combination of strength and adaptability allows surgeons to effectively address complex facial injuries, leading to better patient satisfaction and quality of life.
As the medical field continues to advance, the applications of ASTM F136 titanium are expected to expand further. Innovations in additive manufacturing, or 3D printing, have the potential to revolutionize the way titanium implants are produced. This technology allows for the creation of custom implants tailored to the unique anatomy of each patient, improving surgical outcomes and reducing recovery times. Furthermore, researchers are exploring the development of bioactive coatings that can enhance bone integration and promote faster healing, making titanium implants even more effective.
Looking ahead, the integration of smart technology into titanium implants could provide real-time monitoring of healing processes, enabling surgeons to make informed decisions during recovery. These advancements will not only improve patient outcomes but also pave the way for more personalized treatment options in the medical industry.
ASTM F136 titanium plates and sheets represent a significant advancement in the medical industry, combining biocompatibility, strength, and corrosion resistance to meet the demands of modern surgical practices. Their applications span a wide range of specialties, from orthopedics to maxillofacial surgery, enhancing the effectiveness of various procedures. As innovations continue to emerge, the future of titanium in the medical field looks promising, with the potential to further improve patient care and surgical outcomes. The ongoing commitment to research and development in this area ensures that ASTM F136 titanium will remain a vital component in the evolution of medical technology.
| Production Name | 6-2-4-2 Titanium plate |
| Size |
T 0.5-5.0mm x W1000mm x L 2000-3500mm T 6.0- 30mm x W1000-2500mm x L 3000-6000mm T 30- 80mm x W1000mm x L 2000mm |
| Material grade | (6-2-4-2 )Ti-6Al-2Sn-4Zr-2Mo-0.1Si |
| Standard | ASTM/ASME B265 |
| Surface | Bright/ polished |
| Technique | Rolled, forged |
| Supply status | M (Y/ R) |
| Feature | High corrosion resistance, low density, good thermal stability |
| Certificate | ISO 9001:2008; The third test report; TÜV Rheinland; Supplier Assessment Certificate |
| 6-2-4-2 titanium plate | ||||||
| Chemical compositions(weight%,<=) | ||||||
| Al | Sn | Mo | Zr | Si | Fe | C |
| 5.5-6.5 | 1.8-2.2 | 1.8-2.2 | 3.6-4.4 | <=0.13 | 0.25 | 0.05 |
| N | H | O | Other(total) | Ti | ||
| 0.05 | 0.0125 | 0.15 | 0.3 | Remainder | ||
| Physical properties(>=) | ||||||
|
Σb Tensile Strength (Mpa) |
σr0.2 Yield Strength (Mpa) |
δL0+50mm Elongation (%) |
ψ
Reduction of area (%) |
|||
| 620 | 483 | 15 | ---- | |||
Medical titanium sheets are thin, flat materials crafted from titanium alloys for various medical uses. Among the most recognized grades is Grade 5 (Ti-6Al-4V), prized for skull implants and orthopedic devices due to its optimal strength-to-weight ratio. Ti-6Al-7Nb is another key alloy, ideal for fixation devices, thanks to its excellent mechanical properties and biocompatibility that supports bone integration.
Additionally, ASTM F136 is favored in dental implants for its superior mechanical strength, ensuring durability. ISO 5832-3 pure titanium is selected for its high biocompatibility, making it safe for direct tissue contact. Grade 1 titanium, noted for its excellent ductility and corrosion resistance, is particularly suitable for fracture fixation. Together, these grades highlight the versatility and critical role of medical titanium sheets in enhancing patient care and surgical outcomes.
To ensure high quality, look for:
Detailed images:
| Parameters | Value |
|---|---|
| Shape | Sheet |
| Tensile Strength (P.S.I) | 35000 |
| Surface | Polished |
| Corrosion Resistance | Excellent |
| Formability | Good |
| Thickness (mm) | 0.5-6 |
| Hardness (Rockwell B) | 80 |
| Yield Strength (P.S.I) | 25000 |
| Density (G/cm3) | 4.51 |
| Elongation (in 2) | 20% |
Titanium Sheet offers comprehensive technical support and services for our customers. Our skilled team of engineers and technicians is available around the clock to address any questions or concerns regarding our products. We provide online documentation, tutorials, and video guides to help you maximize the benefits of your Titanium Sheet.
In addition to technical support, our customer service team is ready to assist with any issues you may encounter. We are committed to resolving your questions and problems promptly, and we offer free repair and replacement for defective parts.
We aim to deliver the best customer experience with our Titanium Sheet products. Feel free to reach out with any inquiries or concerns!
The LHTi Titanium Alloy Sheet is a premium product from China, offering a yield strength of 25,000 PSI. With a polished silver surface and a density of 4.51 g/cm³, it delivers exceptional corrosion resistance. Its combination of high strength and low weight makes it ideal for diverse applications, providing excellent oxidation and wear resistance.
This versatile alloy sheet is well-suited for industries such as aerospace, automotive manufacturing, power generation, and healthcare. It's commonly used in the production of aircraft components, high-performance vehicles, medical implants, and products like bicycles and boats.
Overall, the LHTi Titanium Alloy Sheet is an outstanding choice for projects that demand strength, lightweight properties, and corrosion resistance. Its polished finish adds visual appeal, making it a reliable, high-quality option for various applications.
Titanium Sheet products are carefully packaged in boxes or crates with plastic lining to prevent damage during transit. For larger orders, the sheets are securely strapped together to maintain their integrity throughout shipping. All orders are dispatched within two business days of payment via a trusted courier service. Customers receive tracking numbers to monitor their shipment.
